The story
Infineon has announced a new manufacturing push in Villach, Austria, that moves gallium nitride, or GaN, power semiconductors from today’s smaller-wafer production toward 300-millimeter high-volume manufacturing . The company says the project will be the world’s first high-volume manufacturing facility for next-generation GaN power semiconductors on 300-millimeter wafers, and it plans to invest about €1.1 billion in the site by 2034 . Production is scheduled to begin by the end of 2027, with the ramp aligned to market demand rather than presented as an immediate full-capacity switch-on .
That distinction matters. This is not a conventional announcement about leading-edge logic chips or GPUs. It is about power semiconductors: devices that switch, convert and manage electricity inside data centers, electric vehicles, energy infrastructure, robotics and consumer electronics . GaN is valuable because it can switch electricity faster and with lower losses than conventional silicon power devices, enabling smaller systems, reduced heat and higher efficiency , .
Infineon’s move is also not simply “a new fab” in the greenfield sense. The company says it will use existing cleanroom facilities in Villach and upgrade infrastructure to expand capacity efficiently . The European Commission’s state-aid coverage similarly describes the project as an upgrade of Infineon Technologies Austria’s existing semiconductor facility in Villach, rather than a factory built from scratch .
Why 300 millimeters changes the economics
The core manufacturing point is wafer size. Infineon says producing GaN chips on 300-millimeter wafers is more efficient than on 200-millimeter wafers because the larger diameter yields about 2.3 times as many chips per wafer . In simple terms, the move gives GaN access to the economics of the silicon-adjacent industrial empire: more devices per disc, more automation potential, and a better route to scale if yields and demand support the ramp.
That does not mean total factory output automatically multiplies by 2.3. Wafer starts, yields, tool availability, qualification cycles and product mix still determine how many saleable devices reach customers. But the wafer transition creates a larger production canvas for a material that has often been associated with fast chargers and specialized power designs, and is now being pushed toward broader infrastructure markets.
Infineon says it first successfully processed 300-millimeter GaN wafers two years ago and is now transferring that technology into a high-volume facility serving customers . eeNews Europe also framed the program as a commercial scale-up of GaN technology, with implications for power electronics designers who need better manufacturing economics before adopting GaN more widely .
Villach becomes the European GaN beachhead
Villach is already a major Infineon center for power electronics and new semiconductor materials . The new 300-millimeter GaN program reinforces that role by tying manufacturing to the region’s research and development base . Infineon Austria employs about 5,800 people, including roughly 4,800 in Villach, according to the company’s latest stated figures .
The European Commission approved €319 million in Austrian state aid for the project, with the funding intended to support the transition from existing 200-millimeter power GaN manufacturing in Villach to larger 300-millimeter wafers . The Commission described the facility as first-of-a-kind in the European Union because power GaN devices are currently manufactured on wafers up to 200 millimeters, and no comparable 300-millimeter power GaN manufacturing capacity exists in the bloc .
The aid will take the form of a direct grant, and the Commission attached conditions: Infineon is expected to expand cooperation with startups, small and medium-sized companies, universities and research institutions, including access to hardware and software kits and laboratory facilities . Infineon also committed to skills and education activities, and to sharing with Austria potential project-related profits beyond current expectations . eeNews Europe noted that formal funding approval from Austria’s federal ministry was still pending even after the Commission approval .
Strategic sovereignty, but in power conversion
Europe’s chip strategy is often discussed through the lens of processors, memory or advanced lithography. This announcement is different. It strengthens Europe in power conversion, not in conventional computing alone. Power chips are less glamorous than AI accelerators, but they are essential to every electrified system that has to move energy efficiently from one voltage, current or form to another.
Infineon’s own list of target applications shows why that matters: AI data centers, energy infrastructure, e-mobility, robotics and consumer electronics . Data centers need denser and more efficient power delivery. Electric vehicles and charging infrastructure need compact and high-efficiency conversion. Industrial automation and robotics depend on power electronics that can switch quickly while limiting heat. In all of these markets, GaN is part of a broader shift from “make more power” to “waste less power.”
German public broadcaster tagesschau reported that the 300-millimeter wafers are larger than the 200-millimeter wafers used so far and that this creates production-efficiency gains; it also noted Infineon’s plan to use existing cleanroom capacity and start production by the end of 2027 . The same report highlighted the political framing in Austria: public aid under the European Chips Act and a focus on maintaining value creation and jobs in the country .
The business case: scale, revenue and timing
The financial numbers make the ambition clear. Infineon is committing around €1.1 billion through 2034 . Dow Jones reporting carried by MarketScreener said CEO Jochen Hanebeck told reporters the planned production could target about €1.5 billion in annual revenue from these chips . That figure is not the same as guaranteed sales; it is a revenue target tied to the planned manufacturing base and market uptake.
Infineon cites analysts expecting the GaN power semiconductor market to reach about $3.5 billion by 2031, equivalent to roughly 35% annual growth from 2025 to 2031 . eeNews Europe attributed the same market outlook to Yole Group’s Power GaN 2026 report . If that forecast proves broadly right, a 300-millimeter platform could give Infineon a cost and capacity lever at exactly the moment GaN moves beyond early adopter products.
The timing also reflects caution. Production starts by the end of 2027, while investments run to 2034 . That gap suggests a staged buildout, with capacity added as demand materializes and manufacturing maturity improves. Infineon’s release explicitly says the ramp will be aligned with market demand .
What to watch next
The next proof point is not the announcement itself; it is execution. Key questions include how quickly Infineon can qualify 300-millimeter GaN processes for customer programs, what yields look like at scale, and how fast customers in data centers, automotive, energy and industrial markets redesign systems around the devices.
The state-aid file is another area to watch. The Commission said the non-confidential decision will be published under case number SA.113427 once confidentiality issues are resolved . That document should provide a clearer view of the conditions attached to Austria’s grant and the policy logic behind the approval.
Still, the direction is already clear. Infineon is not merely adding capacity; it is trying to industrialize GaN on a wafer format associated with higher-volume semiconductor economics. Bigger wafers do not magically solve every manufacturing constraint, but they do unlock a new tech tree for power electronics: more efficient production, deeper European capability, and a stronger path for GaN into mainstream energy conversion.
